BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

The key facts and figures for the BMW 5 Series Sedan at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

Read more
THE 5BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,655
Max. permissible weight in kg
2,250
Permitted load in kg
670
Permitted axle load front/rear in kg
1,265/1,045
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1.597
Stroke/bore in mm
75.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.9-7.8
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
8.6-8.5
Extra-urban in l/100 km
6.2-5.8
Combined in l/100 km
7.1-6.8
CO2 combined emissions in g/km
162-156
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (HP) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (HP)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,655
Max. permissible weight in kg
2,250
Permitted load in kg
670
Permitted axle load front/rear in kg
1,265/1,045
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1.597
Stroke/bore in mm
75.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.9-7.8
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
8.6-8.5
Extra-urban in l/100 km
6.2-5.8
Combined in l/100 km
7.1-6.8
CO2 combined emissions in g/km
162-156
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (HP) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (HP)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,655
Max. permissible weight in kg
2,250
Permitted load in kg
670
Permitted axle load front/rear in kg
1,265/1,045
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1.597
Stroke/bore in mm
75.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.9-7.8
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
8.6-8.5
Extra-urban in l/100 km
6.2-5.8
Combined in l/100 km
7.1-6.8
CO2 combined emissions in g/km
162-156
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (HP) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (HP)
-
Combined torque Nm
-

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 530e Sedan(1):
Fuel consumption in l/100 km (combined): 1.8–1.6
CO2 emissions in g/km (combined): 40–36


The values of the vehicles labelled with (1) are preliminary.


The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.



Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2



The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
