THE BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

THE 5THE BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

Discover all the data, specifications and dimensions of the BMW 5 Series Sedan here.

Read more

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,605
Max. permissible weight in kg
2,200
Permitted load in kg
660.0
Permitted axle load front/rear in kg
1,045/1,250
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Max. output in kW (hp) at 1/min
135(184)/5,000-6,500
Max. torque in Nm at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.8
Fuel consumption
Urban in l/100 km
7.2-6.9
Extra-urban in l/100 km
5.1-4.6
Combined in l/100 km
5.9-5.4
CO2 emissions in g/km
134-124
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,615
Max. permissible weight in kg
2,200
Permitted load in kg
660
Permitted axle load front/rear in kg
1,045/1,250
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Max. output in kW (hp) at 1/min
185 (252)/5,200-6,500
Max. torque in Nm at 1/min
350/1,450-4,800
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
6.2
Fuel consumption
Urban in l/100 km
7.3-6.9
Extra-urban in l/100 km
5.2-4.7
Combined in l/100 km
5.9-5.5
CO2 emissions in g/km
136-126
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,735
Max. permissible weight in kg
2,340
Permitted load in kg
675
Permitted axle load front/rear in kg
1,160/1,270
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Max. output in kW (hp) at 1/min
250 (340)/5,500-6,500
Max. torque in Nm at 1/min
450/1,380-5,200
Compression ratio : 1
11.0
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.8
Fuel consumption
Urban in l/100 km
9.6-9.3
Extra-urban in l/100 km
6.1-5.7
Combined in l/100 km
7.4-6.9
CO2 emissions in g/km
169-159
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,845
Max. permissible weight in kg
2,420
Permitted load in kg
650
Permitted axle load front/rear in kg
1,120/1,405
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Max. output in kW (hp) at 1/min
135(184)/5,000-6,500
Max. torque in Nm at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
6.2
Fuel consumption
Urban in l/100 km
n/a
Extra-urban in l/100 km
n/a
Combined in l/100 km
2.1-1.9
CO2 emissions in g/km
49-44
Tank capacity, approx. in l
46
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy

FUEL CONSUMPTION AND CO2 EMISSIONS.

* with mild hybrid technology

BMW 540i Sedan:
Fuel consumption in l/100 km (combined): 7.2–7.1
CO2 emissions in g/km (combined): 164–161

The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.

Read more

Fuel consumption and CO2 emissions.

  • * with mild hybrid technology

    BMW 540i Sedan:
    Fuel consumption in l/100 km (combined): 7.3
    CO2 emissions in g/km (combined): 168

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
