TECHNICAL DATA.

    Select model

    Weight

    Unladen weight EU in kg 1515.0
    Max. permissible weight in kg 2090.0
    Permitted load in kg 630.0
    Permitted axle load front/rear in kg 1,045/1,055
    Luggage capacity min. (seats up or roof down) in l 645.0
    Luggage capacity max. (seats down or roof up) in l 1905.0
    Trailer load (unbraked) in kg 735
    Trailer load 8% (braked) in kg 1,500
    Trailer load 12% (braked) in kg 1,500

    Engine

    Cylinders/valves 3/4
    Capacity in ccm 1,499
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (PS) at 1/min 103 (140)/4,500-6,500
    Engine torque (Nm) at 1/min 220/1,480-4,200
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 205.0
    Acceleration 0–100 km/h in s 9.6

    Fuel consumption

    Urban in l/100 km 7.2
    Extra-urban in l/100 km 5.3-5.2
    Combined in l/100 km 6.0
    CO2 combined emissions in g/km 137
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 205/60 R16 96V XL
    Tyre dimensions rear 205/60 R16 96V XL
    Wheel dimensions and material front 7 J x 16 inches, light-alloy
    Wheel dimensions and material rear 7 J x 16 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,560
    Max. permissible weight in kg 2,140
    Permitted load in kg 630
    Permitted axle load front/rear in kg 1,075/1,065
    Luggage capacity min. (seats up or roof down) in l 645.0
    Luggage capacity max. (seats down or roof up) in l 1,905
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,500
    Trailer load 12% (braked) in kg 1,500

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (PS) at 1/min 141 (192)/5,000-6,000
    Engine torque (Nm) at 1/min 280/1,350-4,600
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 222
    Acceleration 0–100 km/h in s 7.6

    Fuel consumption

    Urban in l/100 km 7.2
    Extra-urban in l/100 km 5.5
    Combined in l/100 km 6.1
    CO2 combined emissions in g/km 139
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 205/55 R17 95W XL
    Tyre dimensions rear 205/55 R17 95W XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Information about the data.

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    ¹ Until production date 31.05.18. Please check availability with your dealer.
    The values of the vehicles labeled with ³, are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. [With respect to these vehicles, for vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.]

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
