THE BMW 5 SERIES TOURING: ENGINES & TECHNICAL DATA

THE 5

THE 5THE BMW 5 SERIES TOURING: ENGINES & TECHNICAL DATA

Discover all the data, specifications and dimensions of the BMW 5 Series Touring here.

Read more

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,710
Max. permissible weight in kg
2,350
Permitted load in kg
715
Permitted axle load front/rear in kg
1,055/1,400
Luggage capacity min.-max.in l
570-1,700
Trailer load (unbraked) in kg
750.0
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
290/1,350-4,250
Compression ratio : 1
10.2
Performance
Top speed in km/h
225
Acceleration 0–100 km/h in s
8.2
Fuel consumption
Urban in l/100 km
7.4-7.3
Extra-urban in l/100 km
5.6-5.3
Combined in l/100 km
6.3-6.1
CO2 combined emissions in g/km
143-138
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,715
Max. permissible weight in kg
2,360
Permitted load in kg
720
Permitted axle load front/rear in kg
1,065/1,410
Luggage capacity min.-max.in l
570-1,700
Trailer load (unbraked) in kg
750.0
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
185 (252)/5,200-6,500
Engine torque (Nm) at 1/min
350/1,450-4,800
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
6.4
Fuel consumption
Urban in l/100 km
8.0-7.3
Extra-urban in l/100 km
5.4
Combined in l/100 km
6.3-6.1
CO2 combined emissions in g/km
144-139
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,840
Max. permissible weight in kg
2,495
Permitted load in kg
730
Permitted axle load front/rear in kg
1,185/1,430
Luggage capacity min.-max.in l
570-1,700
Trailer load (unbraked) in kg
750.0
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
250 (340)/5,500-6,500
Engine torque (Nm) at 1/min
450/1,380-5,200
Compression ratio : 1
11.0
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.1
Fuel consumption
Urban in l/100 km
10.6-10.0
Extra-urban in l/100 km
6.6
Combined in l/100 km
8.0-7.8
CO2 combined emissions in g/km
183-178
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 97Y
Tyre dimensions rear
225/55 R17 97Y
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy

Fuel consumption and CO2 emissions.

  • * with mild hybrid technology

    BMW 540i xDrive Touring:
    Fuel consumption in l/100 km (combined): 7.7-7.3
    CO2 emissions in g/km (combined): 177-167

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
